Without being able to control all crusher functions on your remote control you struggle to keep crushing and risk safety.

At RUBBLE MASTER we understand that you can't afford numerous laborers to accomplish various tasks. That's the reason why we offer a radio remote control that helps you dominating your crushing operation. If you are missing functions on the radio remote control you

  • Get out of the cab and within the crusher danger zone
  • Struggle to react to crushing hazards
  • Delay emergency stops



RUBBLE MASTER gives you more control over your portable impact crusher

Every portable RUBBLE MASTER crusher comes standard with a radio remote control. The following functions give you a basic set of control over your portable impact crusher:

Controls for the crawler tracks Proportional tracking makes precision movements for loading and unloading the crusher easy. The RUBBLE MASTER portable impact crusher will track & crush simultaneously so that you can back up the machine and windrow finished product in front of the crusher.
Tracking speed The crusher tracks can be operated in a turtle or rabbit mode. The turtle mode offers torque and precision for loading and unloading the machine from a trailer. The rabbit mode allows a fast movement accross the jobsite.
Track activation By default, the track controls are not enabled and tracking needs to be activated manually via this push button. The machine signals through lighting and the horn that it is ready for tracking.
If the controls for the crawler tracks are not being used for several seconds the tracking mode is deactivated automatically.
Emergency stop

The e-stop button shuts down the entire portable crushing plant

Attention: upon pressing the e-stop in operation the remaining hopper inertia fills up the crushing chamber with material.

Feeder speed Stepless adjustment of the default hopper feed speed
Feeder start/stop The feeder can be activated only when the crusher and discharge conveyors are operational.
Feeder zero speed Feeder stops conveying forward but stays in motion.
Feeder max speed As long as the button is pressed the feeder accelerates to its max speed to push material forward hard.
RM Release System As long as the button is pressed the impact wall is pushed back hydraulically to resolve material blockages.
Magnet conveyor Start/stop with the rebar discharge left or right
Horn
Conveyors start/stop Starts the conveyors in the correct sequence to avoid material blockages or spillages.
Main conveyor reverse When hopper and crusher are turned off the main conveyor can be run in reverse by keeping the conveyor start/stop button pressed for a couple of seconds.
Side discharge conveyor start/stop Activate the fines conveyor underneath the pre-screen (optional)
Information display

The information display shows you the most important stats of your machine such as

  • Error codes
  • Coolant temperature
  • Engine load
  • Engine speed
  • Hopper speed (in % of max speed)
  • Current tracking mode (turtle vs rabbit)
  • Magnet discharge direction





An information display, performance indicator, status lighting, and the RM XSMART telemetry app provide even more clarity on the condition and operational status of your machine.

RUBBLE MASTER portable impact crushers provide comprehensive machine to human communication to support operators so that you can react faster, reduce downtime, and risk less safety.

Information displayX

Every portable RUBBLE MASTER crusher features an information display with the most important machine stats.

Performance indicatorX

All NEXT generation portable RUBBLE MASTER crushers feature a performance indicator to show the current utilization of the machine.

Status lightingX

Every NEXT generation portable RUBBLE MASTER crusher comes with status lighting that shows the condition of the machine.

  • Green: ready to crush
  • Yellow: service needed or tracking mode
  • Red: error

Connect your phone to your portable impact crusher to access even more information.

Jobsites and work schedules tend to get busy and it is hard to stay on top of all the moving parts. At RUBBLE MASTER we understand, that you want to keep crushing and therefore our RM XSMART telemetry assist you in accelerating processes so that you can focus on dominating the jobsite.

  • Keep track of the machine condition
  • Error codes with trouble-shooting guidelines
  • Check fuel and DEF elevels
  • Share jobsite reports with your back-office or client
  • Track tonnages (with optional belt-scale)
  • Zero belt-scale (with optional belt-scale)
Portable Impact Crushers

Capacity
Inlet opening
Transport dimension
Weight
RM 120X
Impact Crusher
350 tph 385 TPH
1,160 x 820 mm 46" x 32"
16,180 x 2,990 x 3,600 mm 52‘10” x 9‘11” x 10‘6“
44,000 kg 95,000 lbs
learn more
RM 100GO! Compact Crusher RM 100GO!
Impact Crusher
250 tph 275 TPH
950 x 700 mm 37" x 28"
14,700 x 2,860 x 3,155 mm 48'3" x 9'5" x 10'5"
33,600 kg 74,500 lbs
learn more
RM 90GO! Compact Crusher RM 90GO!
Impact Crusher
180 tph 200 TPH
860 x 650 mm 34" x 25"
13,470 x 2,550 x 3,050 mm 44'2" x 8'5" x 10'
28,400 kg 62,500 lbs
learn more
RM 70GO! Compact Crusher RM 70GO! 2.0
Impact Crusher
150 tph 165 TPH
760 x 600 mm 30" x 23"
13,300 x 2,360 x 3,100 43'8" x 7'9" x 10'2"
24,200 kg 53,400 lbs
learn more
